I became distracted and started experimenting with creating seamless textures using perlin noise. I really do enjoy creating game assets through code.
Code:
' Some experiments, lots of code for god-knows-what here ...
set window "texgen", 256, 256, false, 2
set redraw off
' Create some interesting textures.
w = 128; h = 128
' Rock.
randomize 16
' Create base image.
rockImage = NoiseImage(w, h, 2, 2, 3)
' Add structure with a noise bumpmap.
tmp = NoiseImage(w, h, 3, 3, 4)
bumpmap = Bumpmap(tmp, 0.075)
ApplyBumpmap(rockImage, bumpmap, 1, 1, 1)
' Don't need these images more.
free image tmp
free image bumpmap
' Modify colors a bit.
ApplyTint(rockImage, 255, 128, 32, 0, 0.75, 1)
ApplyTint(rockImage, 16, 64, 255, 1, 0, 0)
' Brick wall.
randomize 37
bricksImage = NoiseImage(w, h, 2, 2, 4)
' Add structure with a noise bumpmap.
tmp = NoiseImage(w, h, 8, 8, 4)
bumpmap = Bumpmap(tmp, 0.15)
ApplyBumpmap(bricksImage, bumpmap, 1, 1, 1)
free image tmp
free image bumpmap
' Create and apply brick wall bumpmap.
tmp = createimage(w, h)
set image tmp, false
set color 0, 0, 0
cls
set color 255, 255, 255
tw = w/4; th = h/8
for y = 0 to 7 for x = 0 to 4 draw rect x*tw - (y%2)*tw/2 + 2 , y*th + 2, tw - 4, th - 4, true
set image primary
Blur(tmp, 3)
bumpmap = Bumpmap(tmp, 0.35)
ApplyBumpmap(bricksImage, bumpmap, 1, 1, 1)
free image tmp
free image bumpmap
' Modify colors a bit.
ApplyTint(bricksImage, 255, 64, 64, 1, 0, 0)
ApplyTint(bricksImage, 255, 208, 128, 0, 1, 1)
' Display four rock images.
set color 255, 255, 255
draw image rockImage, 0, 0
draw image rockImage, w, 0
draw image rockImage, 0, h
draw image rockImage, w, h
set caret width(primary)/2, 4
center "Press spacebar to continue"
redraw
while not keydown(KEY_SPACE, true) fwait 60
' Display four bricks images.
draw image bricksImage, 0, 0
draw image bricksImage, w, 0
draw image bricksImage, 0, h
draw image bricksImage, w, h
set caret width(primary)/2, 4
center "Press spacebar to quit"
redraw
while not keydown(KEY_SPACE, true) fwait 60
' Bilerp
' ------
' Return bilinear interpolation of four values.
function Bilerp(tl, tr, bl, br, x, y)
return (1 - y)*((1 - x)*tl + x*tr) + y*((1 - x)*bl + x*br)
endfunc
' BilerpV
' -------
' Return bilinear interpolation of four arrays.
function BilerpV(tl, tr, bl, br, x, y)
c = sizeof(tl)
v = dim(c)
ix = 1 - x; iy = 1 - y
for i = 0 to c - 1 v[i] = iy*(ix*tl[i] + x*tr[i]) + y*(ix*bl[i] + x*br[i])
return v
endfunc
' Bumpmap
' -------
' Treat the red color channel of image img as height data and create a bumpmap. normalZ determines
' the roughness of the surface. A low value creates a rougher looking surface, and probably you'll
' usually want to keep the value in the range [0.1 .. 1]. The function returns a new image, but
' this image is actually a normalmap, where a 3d normal is coded into the rgb data of each pixel.
function Bumpmap(img, normalZ)
assert normalZ > 0, "CreateBumpmap: z must be larger than 0"
w = width(img); h = height(img)
map = createimage(w, h)
set image map, false
for y = 0 to h - 1 for x = 0 to w - 1
nx = (Red(pixeli(img, (x + 1)%w, y)) - Red(pixeli(img, (x - 1)%w, y)))/255
ny = (Red(pixeli(img, x, (y + 1)%h)) - Red(pixeli(img, x, (y - 1)%h)))/255
nz = normalZ
k = 128/sqr(nx*nx + ny*ny + nz*nz)
nx = 128 + nx*k; ny = 128 + ny*k; nz = 128 + nz*k
set color nx, ny, nz
set pixel x, y
next
set image primary
return map
endfunc
' ApplyBumpmap
' ------------
' Apply bumpmap bmap, created with CreateBumpmap, to img using the light vector (lightDx lightDy
' lightDz).
function ApplyBumpmap(img, bmap, lightDx, lightDy, lightDz)
w = width(img); h = height(img); wbmap = width(bmap); hbmap = height(bmap)
s = sqr(lightDx*lightDx + lightDy*lightDy + lightDz*lightDz)
lightDx = lightDx/s; lightDy = lightDy/s; lightDz = lightDz/s
set image img, false
' Same size?
if wbmap = w and hbmap = h
for y = 0 to h - 1 for x = 0 to w - 1
c = pixeli(bmap, x, y)
nx = (Red(c) - 128)/128
ny = (Green(c) - 128)/128
nz = (Blue(c) - 128)/128
i = max(nx*lightDx + ny*lightDy + nz*lightDz, 0)
c = pixeli(x, y)
set color Red(c)*i, Green(c)*i, Blue(c)*i
set pixel x, y
next
else
' Use bilinear interpolation of normals.
sx = wbmap/w; sy = hbmap/h
for y = 0 to h - 1 for x = 0 to w - 1
xl = sx*x; xf = xl - floor(xl); xr = (xl + 1)%wbmap
yt = sy*y; yf = yt - floor(yt); yb = (yt + 1)%hbmap
tl = pixel(bmap, xl, yt); tr = pixel(bmap, xr, yt)
bl = pixel(bmap, xl, yb); br = pixel(bmap, xr, yb)
n = BilerpV(tl, tr, bl, br, xf, yf)
n[0] = (n[0] - 128)/128
n[1] = (n[1] - 128)/128
n[2] = (n[2] - 128)/128
' We SHOULD normalize n, but ... meh.
'k = 1/sqr(n[0]*n[0] + n[1]*n[1] + n[2]*n[2])
'n[0] = n[0]*k; n[1] = n[1]*k; n[2] = n[2]*k
i = max(n[0]*lightDx + n[1]*lightDy + n[2]*lightDz, 0)
c = pixeli(x, y)
set color Red(c)*i, Green(c)*i, Blue(c)*i
set pixel x, y
next
endif
set image primary
endfunc
' ApplyContrast
' -------------
function ApplyContrast(img, r, g, b)
set image img, false
for y = 0 to height(img) - 1 for x = 0 to width(img) - 1
c = pixel(x, y)
set color 128 + (c[0] - 128)*r, 128 + (c[1] - 128)*g, 128 + (c[2] - 128)*b
set pixel x, y
next
set image primary
endfunc
' ApplyTint
' ---------
function ApplyTint(img, r, g, b, shadows, midtones, highlights)
r = r/255; g = g/255; b = b/255
filter = []
for i = 0 to 255
filter[i] = max(128 - i, 0)*shadows/128 + max(i - 128, 0)*highlights/128 +
(128 - |128 - i|)*midtones/128
next
set image img, false
for y = 0 to height(img) - 1 for x = 0 to width(img) - 1
c = pixel(x, y)
i = int(c[0] + c[1] + c[2])/3
fi = filter[i]; ifi = 1 - fi
set color fi*c[0]*r + ifi*c[0],
fi*c[1]*g + ifi*c[1],
fi*c[2]*b + ifi*c[2]
set pixel x, y
next
set image primary
endfunc
' BoxBlur
' -------
' Box blur image.
function BoxBlur(img, rx, ry)
rx = max(int(rx), 0); ry = max(int(ry), 0)
set image img
w = width(img); h = height(img)
data = dim(w, h)
' Blur vertically
for y = 0 to h - 1 for x = 0 to w - 1 data[x][y] = pixeli(img, x, y)
count = ry*2 + 1
for x = 0 to w - 1
sr = 0; sg = 0; sb = 0; sa = 0
for y = -ry to ry
p = data[x][y%h];
sr = sr + Red(p); sg = sg + Green(p); sb = sb + Blue(p); sa = sa + Alpha(p)
next
for y = 0 to h - 1
set color sr/count, sg/count, sb/count, sa/count
set pixel x, y
p = data[x][(y - ry)%h]
sr = sr - Red(p); sg = sg - Green(p); sb = sb - Blue(p); sa = sa - Alpha(p)
p = data[x][(y + ry + 1)%h]
sr = sr + Red(p); sg = sg + Green(p); sb = sb + Blue(p); sa = sa + Alpha(p)
next
next
' Blur horizontally.
for y = 0 to h - 1 for x = 0 to w - 1 data[x][y] = pixeli(img, x, y)
count = rx*2 + 1
for y = 0 to h - 1
sr = 0; sg = 0; sb = 0; sa = 0
for x = -rx to rx
p = data[x%w][y]
sr = sr + Red(p); sg = sg + Green(p); sb = sb + Blue(p); sa = sa + Alpha(p)
next
for x = 0 to w - 1
set color sr/count, sg/count, sb/count, sa/count
set pixel x, y
p = data[(x - rx)%w][y]
sr = sr - Red(p); sg = sg - Green(p); sb = sb - Blue(p); sa = sa - Alpha(p)
p = data[(x + rx + 1)%w][y]
sr = sr + Red(p); sg = sg + Green(p); sb = sb + Blue(p); sa = sa + Alpha(p)
next
next
set image primary
endfunc
' Blur
' ----
function Blur(img, r)
if r <= 0 return
for i = 1 to r BoxBlur(img, 1, 1)
endfunc
' NoiseImage
' ----------
' Create noise image using something that is maybe perlin noise.
function NoiseImage(w, h, resX, resY, details)
details = max(details, 1)
octaves = []
for i = 1 to details
octaves[sizeof(octaves)] = CloudMap(resX, resY)
resX = resX*2; resY = resY*2
next
img = createimage(w, h)
set image img
for y = 0 to h - 1 for x = 0 to w - 1
nx = x/w; ny = y/h
v = 0; amp = 1
for i = 0 to sizeof(octaves) - 1
v = v + octaves[i].ValueAt(nx, ny)*amp
amp = amp*0.5
next
v = 255*(0.5 + 0.5*v)
set color v, v, v
set pixel x, y
next
set image primary
return img
endfunc
' CloudMap
' --------
function CloudMap(resX, resY)
map = []
' Create grid of random unit vectors.
map.m = dim(resX, resY)
for y = 0 to resY - 1 for x = 0 to resX - 1
a = rnd()*PI*2
map.m[x][y] = [x: cos(a), y: sin(a)]
next
' ValueAt
' -------
' Return value, [-1..1] at coordinates (x, y), The size of the cloud is 1x1, but the coordinates
' are wrapped and the cloud is always seamless.
map.ValueAt = function(x, y)
m = this.m
w = sizeof(m); h = sizeof(m[0])
x = (x*w)%w; y = (y*h)%h
x0 = floor(x); y0 = floor(y)
x1 = (x0 + 1)%w; y1 = (y0 + 1)%h
fx = x - x0; fy = y - y0
tl = -fx*m[x0][y0].x - fy*m[x0][y0].y
tr = (1 - fx)*m[x1][y0].x - fy*m[x1][y0].y
bl = -fx*m[x0][y1].x + (1 - fy)*m[x0][y1].y
br = (1 - fx)*m[x1][y1].x + (1 - fy)*m[x1][y1].y
return Bilinear(tl, tr, bl, br, Quad(0, 1, fx), Quad(0, 1, fy))
' Bilinear
' --------
function Bilinear(tl, tr, bl, br, x, y)
ix = 1 - x
return (1 - y)*(ix*tl + x*tr) + y*(ix*bl + x*br)
endfunc
' Quad
' ----
function Quad(a, b, p)
return a - 3*a*p^2 + 2*a*p^3 + 3*b*p^2 - 2*b*p^3
endfunc
endfunc
return map
endfunc
' Pixeli helpers.
function Alpha(c); return int(c/16777216); endfunc
function Red(c); return int((c/65536))%256; endfunc
function Green(c); return int((c/256))%256; endfunc
function Blue(c); return c%256; endfunc
function ToRGB(r, g, b); return 255*16777216 + r*65536 + g*256 + b; endfunc
function ToRGBA(r, g, b, a); return a*16777216 + r*65536 + g*256 + b; endfunc
' RNG
' ---
' Return a random number generator. It can be useful if you need multiple independent series,
' especially if one or more of them needs to be fixed.
function RNG(seed)
r = []
' SetSeet
' -------
r.SetSeed = function(seed)
this.s = max(int(seed), 1)
endfunc
' Next
' ----
' Return next random number in the range [0..2147483646].
r.Next = function()
this.s = int((16807*this.s)%2147483647)
return this.s
endfunc
' Int
' ---
' Return a random int in the range [0..n - 1], negative if n is negative.
r.Int = function(n)
n = floor(n)
if n > 0 return this.Next()%n
elseif n < 0 return -this.Next()%(-n)
else return 0
endfunc
' Float
' -----
' Return a random float in the range [0..1].
r.Float = function()
return this.Next()/2147483647
endfunc
' Range
' -----
' Return a random int in the range [rmin..rmax], works like.
r.Range = function(rmin, rmax)
rmin = int(rmin); rmax = int(rmax)
if rmin > rmax
tmp = rmin; rmin = rmax; rmax = tmp
endif
return floor((this.Next()/2147483647)*(rmax - rmin + 1) + rmin)
endfunc
r.SetSeed(seed)
return r
endfunc
So I'm not sure if this is actually Perlin Noise, but it gives a nice result. This example just shows some clouds with different detail levels, but you can also use it to create really cool plasma images (I might post some of that later). These clouds can be used as heightmaps for terrain.
